VicalloyⅡ
Forms: Bar/Rod/Disk
Description
Vicalloy Ⅱ is an Iron-Cobalt-Tungsten ductile permanent magnet alloy. The material is used in electrical and electrical and electronic application.magnetic properties are optimized by heat-treating cold rolled material.VicalloyⅠ has a relatively high remanence and low coercive force.
Application
Vicalloy Ⅱ has been used for biasing magnets in meters and magnetic actuators, as magnetic coded devices, field coils for DC motors and servos, and hysteresis motor laminations.
parameter
Cross Reference
| Russia | Standard |
| 12KB14 | GB/T14988-1994 |
Chemical Composition (%)
| C | Si | P | S | Co | W | Mn | Fe |
| ≤ | |||||||
| 0.03 | 0.30 | 0.025 | 0.025 | 11.0~13.0 | 14.0~15.0 | ≤0.70 | Balance |
Mechanical Property
Magnetic Property
Size Range
| Bar | Dia 8.0mm~Dia 32.0mm,length:≤3000mm |
| Dia32.0mm~Dia150.0mm,length:≤1300mm |
Condition: (With max tolerance) hot rolled,bright,bright annealed,hot forging,peeled,turned,hot treated
XAGY Advantages
1. High-qulity product
- ISO9001:2008 International Quality System Certification.
- With advanced equipments: VIMF, Induction Furnace, ESR Furnace ect.
- Strict Quality-testing System.
2. Strong R & D Strength
- 40,000㎡ production base.
- 60+ R & D team members, with rich customization experience.
- A good assortment of alloy to choose.
3. Efficient delivery
- Flexible transport means, very convenient.
- Tailor a suitable transport plan.
4. Good service
- We provide online service, information feedback within 24 hours.
- Professional team to provide remote technical advice and guidance.
